260 Single-row Progressive Lamination Stamping Mold
260 Single-row Progressive Lamination Stamping Mold
Specification Parameters
Comprehensive life: ≥160 million punches
Blade die life: ≥5 million strokes/0.1mm
Mold structure: Three-plate mold base + ball guide
Effective cutting edge height: ≥8mm
Blade material: DJ40
Grooved die form: Punch grooved die, slow wire finishing, the punch is polished using a special process to remove the oxidation layer
Guide parts: Precision + high hardness
Blanking speed during running-in period: 80-280 punches/minute
Blanking speed: 280-300 punches/minute
Concentricity: ≦0.05mm
Protection device: Equipped with misfeed protection device
Punching burr: ≦0.05mm
Riveting force: 30N
Safety device: Misfeed detection + equal height limit column
Product output form: Conveyor belt
Rotor control device
Chute control device
Plate control device: Cylinder
Mold base material: Upper and lower mold seats P20, middle unloading seat P20, the second and fourth levels are made on the same set of molds and are interchangeable during production. The shaft hole can be used for three interchangeable pumping plates.
Spare parts provided: 30% of wearing parts
Internal plate material: Cr12MOV
