YE3 Series Three-Phase Asynchronous Motors
YE3 Series Three-Phase Asynchronous Motors
Applicable scope: General-purpose places that need energy conservation and continuous operation, such as fans, pumps, etc.
YE3 Series Three-Phase Asynchronous Motors are high-efficiency three-phase asynchronous motors, which are manufactured in accordance with the national GB18613-2020 “Functional efficiency limits and energy efficiency levels of small and medium-sized three-phase asynchronous motors” and the relevant industry standards. The efficiency standards of YE3 series motors meet the national requirements of energy efficiency level 2 and are consistent with IE4 of IEC60034-30, and meet the national requirements of evaluating values of energy conservation for motors.
Technical Parameters
Frame size
80 ~ 355mm
Power
0.75-315KW
Number of poles
2P, 4P, 6P, 8P
Energy efficiency level
YE2
Duty type
S1
Rated voltage
380V
Rated frequency
50Hz/60Hz
Protection level
IP55(IEC34-5).
Cooling method
IC411(IEC34-6)
Features
Beautiful appearance, high efficiency and energy saving, Class F insulation, protection level IP55, low noise, low vibration and reliable and stable operation.
