IP LC/SC FIBER CABLE
The IP connector together with supported cable is applied to 4G,5G, Base Station remote radios, and fiber to the antenna transmission. Besides of that, T&S IP patch cord series has outstanding water and dustproof characteristic which is applied to rigorous environment like aerospace, national defence, etc.
Features of IP LC/SC Fiber Cable
l Senko waterproof connector kits
l Factory terminated (tested cables) or field-installable version available
l IP68 water, dustproof and corrosion resistant
l Plug has tolerance free design, free-floating on Z-axis
l The material in the jumper cable is all-weather and UV-resistant
l Mechanical performance: IEC 61754-20, IEC 61754-4 standard
l RoHS and REACH materials compliant
l minimum of 500 repetitions insert and extract
l ODVA Compatible
l Wide range of operational temperature for outside plant –40°C/70°C
l Compatible with a wide range of cables, 5-8mm OD cable with two 2.0mm to 3.0mm jacketed subunits\
Applications of IP LC/SC Fiber Cable
l Multi-purpose Outdoor
l For connection between distribution box and RRH
l Deployment in Remote Radio Headcell tower applications
l Data communication network
l Optical fiber system access network
l Fiber Storage Area Network
l High-density chassis
Standard Compliance of IP LC/SC Fiber Cable
l IEC 61754 series compliant
l Qualified to Telcordia GR-326-Core
l Reach, RoHS and SvHC compliant
Specifications of IP LC/SC Fiber Cable
Product Parameters|Cable Parameters
Performance
Standard
Low loss
Connector
mode
End face
IL (dB)
IL (dB)
IL (dB)
IL (dB)
LC/SC
SM
APC
≤0.30
≥60
≤0.10
≥60
UPC
≤0.20
≥50
≤0.10
≥50
MM
PC
≤0.20
≥20
≤0.10
≥20
