IWRFSOC8X8 Xilinx RFSoC 3U 4-Channel/ DC-4GHz
InterWiser IWRFSOC8x8 3U algorithm evaluation modular system designed for integration into deployed RF systems with small size, low power consumption and real-time processing requirements. The IWRFSOC8x8Xilinx Zynq UltraScale+™ RFSoC Gen 1 is featured with 8 RF-ADCs and 8 RF-DACs. The IWRFSOC8x8 modules and comprehensive software suite, enables rapid prototyping, allowing you to develop application code for IWRFSOC8x8, conveniently shortening product development cycles for rapid verification and deployment. Sample code and tutorials demonstrate Xilinx RFSoC multi-tile synchronization (multi-converter synchronization) and multi-board synchronization analog capture.
Performance indicators:
FPGA chipZynq UltraScale+ XCZU27DR-ffve1156 RFSoCRF interfaceX8ADC (12-bit, 4.096GSPS) portsX8DAC (14-bit, 6.554GSPS) portOptical port rateCompatible with 100Gbps/40Gbps (1)Compatible with 10Gbps (1)
MemoryPS 4xDDR4 (4GB, 64bit, 2400MT/s)PL 2xDDR4 (4GB, 64bit, 2666MT/s)Hard disk1 SATA hard disk expansion interface (6G speed)
Board power supplyATX power supply interface (DC +12V)
PS interface2x QSPI flash (512MB, 8bit) fixed configuration file1x SATA .M2 hard disk expansion interface (6G speed)1x 10/100/1000 Ethernet RGMII (RJ45) network port1x USB_JTAG/UART debug interface1x JTAG debug interfacex Micro SD CardPL interface8-channel ADC (12-bit, 4.096GSPS) port8-channel DAC (14-bit, 6.554GSPS) port2x GPIO X16 PMOD PortClockSupport external clock
Power Consumption25W (depending on the purpose, based on the actual measured value) Ambient temperature requirement-40℃~110℃ when working
