Led Street Light Housing Manufacturers Introduce The Installation Methods Of Different Lamps
Led Street Light Housing Manufacturers introduces the installation methods of different lamps:
1. Pendant lamp: When the chandelier is installed on the top surface of concrete, it can be fastened by embedded parts, penetrating bolts and expansion bolts. During installation, the size of the expansion bolts used can be determined according to the theme and weight of the lamp, but the minimum should not be smaller than M6 (mm), the multi-head chandelier should not be smaller than M8 (mm), and the number of bolts should be at least 2. Light self-tapping screws cannot be used.
2. Ceiling lamp: The ceiling lamp has a round, square or rectangular base (chassis), the size of the base varies. The base of the lamp can be fastened with tube-expanding bolts, or can be fastened with wood screws on the embedded wooden bricks. If the diameter of the base of the lamp holder exceeds 100 mm, 2 screws must be used. If the lamp base is installed with embedded bolts and penetrating bolts, the bolt diameter shall not be less than 6 mm. Wood screws can be used to fix the luminaire on the base, and the number of wood screws should not be less than the number of mounting holes given for the luminaire.
3. Wall lamp: The wall lamp can adopt a base or not according to the structure of the base. When using the base table, you should fix the base table first, and then fix the wall lamp on the base table. The bottom table is generally made of wood, the thickness of the wood should be greater than 15 mm, and the surface is painted with decorative paint. When the wall lamp is installed, it can be fixed by screwing in the screw hole of the lamp position box, or it can be fixed by drilling holes in the wall, pre-embedded wooden bricks or using plastic expander screws. The wall lamp base screws are generally no less than 2 pcs. The installation height of the wall lamp is generally 2 to 2.2 meters from the center of the lamp to the ground, and 1.2 to 1.4 meters for the wall lamp installed at the head of the bed.
4. Downlights: Downlights are recessed lamps and are suitable for use on suspended ceilings. The basic form of the lamp is cylindrical, and the lamp socket is a lead-plated, titanium-plated or nickel-plated metal wide-sided ring. After the lamp is installed, it will be close to the top surface and has a good decorative effect. There is a circlip on each side of the symmetrical tube body of the lamp as a device for fixing the downlight. The opening is in the direction of the lamp socket, and the spacing of the circlips is adjusted with a butterfly nut. installation steps:
5. According to the size and installation position of the downlight, scribe and drill holes on the ceiling.
6. Connect the power cord reserved in the ceiling to the downlight.
7. Adjust the wing nut of the downlight to fix the spring leaf so that the height of the spring leaf is the same as the thickness of the ceiling.
8. Push the downlight into the ceiling opening and install a suitable bulb
Through the above introduction, High Quality Street Light Housing Manufacturers hopes that you can simply refer to the content of this article in future use.
