Planetary Gear Reducer
Planetary Gear Reducer
https://www.reducerbosno.com/products/planetary-gear-reducer.html
Sizes and Range
The Planetary Gear Reducer PX series offers 27 sizes, ranging from 9 to 36, featuring a highly modular design.
Rated output torques range from 22 to 2600 kNm, and speed ratios from 25 to 4000. Even higher speed ratios can be achieved by combining with the R, K, or S series reducers.
Structure
The planetary gear reducer PX series reducer housing is constructed of high-strength ductile iron, with the internal gear directly forming the outer shell.
Shaft Options
The Planetary gear reducer PX series offers coaxial, bevel, helical, and bevel-helical input options.
The planetary gear reducer output shaft options include hollow shaft with expansion disc, hollow shafts with involute spline, solid shafts with parallel key, and solid shaft with involute spline.
Mounting options
The planetary gear reducer offers mounting options, include horizontal, vertical, and torque arm mountings.
We provide customized solutions to meet customer needs.
How Planetary Gear Reducers Work
The configuration of a planetary gear reducer creates a power advantage by moving energy from the sun gear through the planet gears to the carrier, slowing speed while increasing torque ratio, all in a space-saving design. Planetary gear reducers are the most common type of coaxial gearbox, where input and output shafts align on the same axis.
High-quality planetary gear reduction box engineered for your industry.
