11.6 Inch Circular Capacitive Touch Screen with ILITEK Controller
Semijei-Tech’s 11.6 inch circular touch screen is a custom projected capacitive touch panel designed for equipment that requires a distinctive round front interface rather than conventional rectangular glass.
The circular capacitive touch screen combines a 450 mm circular cover lens, G+G construction, 10-point multi-touch and an ILITEK touch controller. It is suitable for custom HMI systems, interactive terminals, smart equipment and commercial products where both touch functionality and industrial design are important.
11.6 InchPCAP Touch Area
450 mmCircular Cover Lens
10-PointMulti-Touch
ILITEKTouch Controller
Why Choose This Circular Capacitive Touch Screen?
Circular Cover Glass Design
The main difference between this product and a conventional PCAP panel is its round front form. The 11.6 inch circular touch screen uses a 450 mm circular cover lens to create a distinctive interface that can become part of the equipment’s exterior design.
Round cover glass appearance
Suitable for non-standard product enclosures
Custom printing and color options
Custom sensor and FPC integration available
10-Point PCAP Multi-Touch
The round capacitive touch screen supports up to 10 simultaneous touch points, making it suitable for graphical HMI interfaces and gesture-based control.
Up to 10 touch points
Swipe, zoom and gesture interaction
Fast touch response
Suitable for interactive commercial and industrial interfaces
ILITEK Controller Integration
The current configuration uses an ILITEK touch controller with COB connection. USB, RS232 and I2C interface options make integration possible with a range of embedded computers and control systems.
Touch parameters can also be tuned according to the cover glass, operating system and application environment.
Durable G+G Structure
The glass-to-glass PCAP structure combines a 3 mm cover glass with a 0.7 mm touch sensor for a durable front interface.
≥6H surface hardness
≥85% transmittance
-20°C to +60°C operating temperature
AG / AR / AF and other treatments available
