H Type Full Automatic Broiler Chicken Cage
The H-shaped fully automatic broiler cage is a multi-layer three-dimensional breeding equipment specially designed for modern intensive broiler farming. It adopts an H-shaped frame structure and integrates automatic feeding, drinking water, manure cleaning, environmental control and ventilation systems.
Technical Parameters
Item
Details
Cage Type
H-type
Number of Layers
3/4/ tiers
Number of Rows
2/3/4/5/6 rows
Birds Per Cage
32-39 birds
each set size (L*W*H)
1250*1000*1900mm (3tiers cage)
Single Cage Size (L×W×H)
Approx. 1250×500×450 mm
Material
Hot-dipped galvanized / high zinc wire
Wire Diameter
Bottom wire: 2.2/2.5 mm; Side wire: 2.5/2.8 mm
Mesh Size
Bottom mesh: 20×30 mm; Side mesh: 25×50 mm
Supporting Equipment
Automatic feeding, drinking, manure removal,ventilation
Suitable For
Commercial broiler chicken
Advantages
High stocking density, space-saving, high automation, easy management
Suitable Scale
Largescale and intensive layer farms
Adopting a 4-8-layer stacked H-shaped structure, it has an extremely high vertical space utilization rate. The stocking density per unit area is 3-4 times higher than that of traditional floor rearing. The Chicken Cages frame is made of high-strength hot-dip galvanized steel, which has undergone anti-corrosion treatment and can adapt to the high-humidity environment of broiler rearing, with a long service life.
The cage net is designed with an increased density to prevent foot injuries to broilers. The cage floor is made of a specific elastic material or has a reasonable mesh size to ensure the broilers’ comfort when standing and effectively reduce the occurrence of breast blisters and leg diseases. The Broiler Chicken Cage door is designed for easy manual observation and chicken catching operations.
