H Type Full Automatic Pullet Cage
The H-shaped fully automatic brooding cage is a high-end brooding equipment specially designed for modern intensive chicken farms. It adopts a multi-layer three-dimensional H-shaped structure and integrates an automatic control system to achieve fully automated operations from feeding, drinking water, manure removal to environmental control.
Technical Parameters
Item
Details
Cage Type
H-type
Number of Layers
3-6tiers
Number of Rows
2/3/4/5/6 rows
Birds Per Cage
30 birds/cell
each set size (L*W*H)
1400*1200*2200mm (4tiers cage)
Single Cage Size (L×W×H)
Approx. 1400×600×430 mm
Material
Hot dipped galvanized/cold galvanized wire
Supporting Equipment
automatic feeding, drinking, manure removal,ventilation
Suitable For
Commercial pullet chicken
Advantages
High stocking density, space-saving, high automation, easy management
Suitable Scale
Largescale and intensive chick farms
Key Features
The H-shaped frame design is adopted, with independent ventilation and operation channels between layers. This not only ensures structural stability and strong load-bearing capacity but also significantly increases the space utilization rate of the chicken house. Compared with traditional floor rearing or simple cage rearing, the stocking density can be increased by more than 50%.
Equipped with temperature control, humidity control and ventilation systems, it can precisely adjust the temperature, humidity and ventilation volume in the house according to the different age requirements of the chicks, ensuring that the chicks are in the best growth environment and reducing stress responses.
The H-shaped fully automatic Chick Cage is particularly suitable for medium and large-scale chicken farms. It can effectively solve the problems of low space utilization, high labor intensity, and difficult disease control in traditional brooding. It is currently the mainstream choice in the brooding stage of the chicken farming industry.
