Ductile Iron Pipe K9C40C30C25

The T-type Joint Pipes (Push-on) produced by our company range from DN80mm to DN2600mm are flexibly jointed with sockets and spigots; they are the first choice in urban water pipe networks due to their convenient installation, strong seismic performances, seal ability and corrosion resistance.

Type:

The T-type Joint Pipe (Push-on)

Standard:

ISO2531, EN545, EN598, etc

DN:

DN80mm~DN2600mm

Material:

Ductile Cast Iron

Pressure:

PN10, PN16, PN25,PN40

Wall Thickness:

K9, K8, C25, C30, C40

Length:

6m, cut to 5.7m

Application:

Water supply project, drainage, sewage, irrigation, water pipeline.

Internal Coating:

a). Portland cement mortar lining

b). Sulphate Resistant cement mortar lining

c). High-Aluminum cement mortar lining

d). Fusion bonded epoxy coating

e). Liquid epoxy painting

f). Black bitumen painting

External Coating:

a). zinc+bitumen(70microns) painting

b). Fusion bonded epoxy coating

c). Zinc-aluminum alloy +liquid epoxy painting

For more about Ductile Iron Pipes, please contact us.
