EZCAD3 Laser and Galvo Control Software | Laser Marking SoftwareIt has a completely new architecture, significantly speeding up data processing speed, and can meet high-precision technical requirements.
Combined both 2D and 3D functionality.
Added high-performance motion control expansion capabilities, supports large-format processing control.
Connects via Ethernet, with unrestricted transmission distance, enabling remote control operations.
Supports various mainstream laser types.
onfigurations
Software Kernel
64 Bit
Laser
Supports CO2, YAG, FIBER, SPI, QCW, CW,etc., and can adjust current, pulse frequency, duty cycle, and other parameters based on different laser parameters through software. Can display the laser status in real-time, and JCZ laser digital communication protocol 1.0 supports almost all lasers available in the market.
Red Light Display
Supports red light as an indicator
Password Control
Supports password protection to prevent unauthorized parameter changes
IO Control
Added port control functionality for easy automation of your machine
Galvo Calibration
3D calibration, traditional trapezoidal correction, barrel (pillow) correction, and parallelogram correction. Specialized calibration software to achieve extremely precise calibration results.
Fill
Background fill, circular fill, arbitrary angle fill, cross fill, adjustable margins, borders, and spacing. Supports 8 layers of filling, with independent parameter settings for each layer
Editing Functions
Multi-layer, 3D curve marking, slicing, dynamic filling, 3D curve projection, surface wrapping, bitmap to embossing, arbitrary curve text, arbitrary graphic drawing/editing, scatter/combine, group/ungroup, undo/redo, welding, trimming, cross, alignment, automatic curve connection, etc
Text Input Function
Supports TrueType fonts, single-line fonts (JSF), dot matrix fonts (DMF), SHX, and supports user-created font libraries
256 Layer Processing Parameters
Highly customizable for easy multi-parameter marking
Barcodes and QR Codes
Code39, EAN, PDF417, DATAMATRIX, QR, PostNet, PL ANET, UK Royal Mail 4 state customer, AZTECCODE, MicroQRCODE, VERICODE etc
Vector Files
PLT、DXF、Al、DST、SVG、GBR、NC、JPC、BOT
Bitmap Files
BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF, Supports segmented processing
Variable Text
Fixed text, date, time, keyboard input, skipping numbers, list files, dynamic files, supports Excel sheets, TXT files, serial communication, and network communication
Multi-Language Support
Built-in Chinese, English, Korean, Japanese, French, German; can be easily localized by language packs for translation
Optional Features
Four-axis point-to-point motion, Dual-axis splicing, flying marking, software secondary development
Calibration Table
Supports loading and switching between up to 4 calibration tables simultaneously
Multi-Layer XY Plane Calibration
Supports, greatly improving the XY plane calibration accuracy of 3D calibration
Offline Mark
Supports switching and processing of up to 16 offline layers
Online Circular Arc Interpolation Commands
Supports, for high-precision small circle processing
Three-Dimensional Model Files
STL, DXF
Processing Functions
Large-format dynamic focusing, projector positioning, multi-axis expansion, estimated processing time, ultra-fast point-like 2D barcode marking, uniform fill function, gradual power and speed control, circular and sine curve jitter, material parameter assistant function
